UL Thermostat Cable - Type CL-P3

*Product images are for illustrative purposes only and may differ from the actual product.

UL Thermostat Cable - Type CL-P3

Download Spec Sheet

UL Thermostat Cable - Type CL-P3

Plenum Rated
UL Listed Type CL-3P

Construction
Category Conductor Description Solid bare copper
Category Insulation Description Plenum, low smoke Polyvinyl Chloride (PVC)
Category Jacket Description Plenum, low smoke Polyvinyl Chloride (PVC)

Questions & Answers

Ask a Question

Part Number Table

Part # Gauge Conductors Insulation Thickness Jacket Thickness Outside Diameter Inches Material Weight (Lbs./M')
G91802 18 2 0.01 0.009 0.142 16.8
G91803 18 3 0.008 0.016 0.151 23
G91804 18 4 0.008 0.016 0.166 29.2
G91805 18 5 0.008 0.016 0.182 36
G91806 18 6 0.008 0.016 0.199 41.4
G91808 18 8 0.008 0.016 0.216 53.9
G91810 18 10 0.008 0.016 0.263 76

* Also available in bulk lengths Note: The data shown is approximate and subject to standard industry and manufacturer tolerances
