Panduit ABM100-S6-D, Wire Routing, Management & Protection #ABM100-S6-D

Home > Panduit ABM100-S6-D, Wire Routing, Management & Protection
Panduit ABM100-S6-D, Wire Routing, Management & Protection

*Product images are for illustrative purposes only and may differ from the actual product.

Panduit ABM100-S6-D, Wire Routing, Management & Protection

Download Spec Sheet

Panduit ABM100-S6-D, Wire Routing, Management & Protection

Part #: ABM100-S6-D
The cable tie mount in white is mounted with a #6 (M3) screw or user supplied adhesive. It is 1" long x 1" wide (25.4 x 25.4 mm), made of nylon 6.6, which increases mechanical strength, heat and wear resistance, and stiffness. It is used with cable ties M, I, and S, is designed for indoor environments, and comes in packages of 500. Sold in and priced as packages of 500.

Please select all above options before adding to cart.

Carton Qty 5000
Carton Weight 14.9000 pounds
Category Wiring, Ducts, & Accessories
Height 0.2 inches
Manufacturer Panduit
Material Nylon 6.6
Max Operating Temperature 85 degrees celsius
Min Operating Temperature -40 degrees celsius
Overall Length 1 inches
Package Qty 500
Package Volume 0.1278 cubic feet
Package Weight 1.4900 pounds
Product Class Wire Routing, Management & Protection
Product Color White
Standard Carton Height 10.91 inches
Standard Carton Length 14.46 inches
Standard Carton Width 14.46 inches
Standard Package Height 1.5 inches
Standard Package Length 16 inches
Standard Package Width 10 inches
UPC 74983384464
Width 1 inches
